Our 12 pin pin connector is a high-performance product designed specifically to meet diverse electronic connection needs. It stands out among numerous connector products with excellent quality and stable performance.
The connector adopts a single row design with 12 circuit pins and a pin spacing of 2.5mm, providing sufficient and reasonable spatial layout for signal transmission and power supply. Its installation direction is a right angle (90 degrees), and the installation type is through-hole welding, which meets the welding temperature of 250 ± 5 ℃. It can ensure a firm and reliable connection with the circuit board during the welding process, effectively reducing the probability of poor contact and other problems.
From the perspective of performance parameters, its rated current can reach 3A and rated voltage is 250V, which can adapt to various common circuit environments. The contact resistance is controlled at 20m Ω Max, greatly reducing losses during signal transmission; The insulation resistance reaches up to 1000M Ω Min, providing excellent insulation performance and ensuring the safety and stability of the circuit; The withstand voltage is 1000V AC/minute, demonstrating excellent voltage resistance.
The working temperature range is -40 ℃ -+105 ℃, and it can work normally in various harsh environments. In terms of material selection, PA66 is used as the plastic material, which meets the UL94V-0 flame retardant rating and has good fire resistance, effectively improving the safety of the product during use. The material of the pin terminal is copper alloy, and conventional electroplating is tin plating, which not only ensures good conductivity, but also enhances the corrosion resistance of the pin and extends the service life of the product.
The 12 pin pin connector is widely used in various electronic devices. In the field of computer science, it can be used for connecting motherboards and expansion cards; In communication equipment, assist in the stable transmission of signals; In automotive electronics, providing reliable connections for various onboard electronic systems; It also plays an important role in the internal circuit connections of consumer electronics products such as mobile phones, tablets, etc.
It has become an ideal choice for many electronic device manufacturers due to its excellent conductivity, space saving design, high current, and low impedance characteristics, providing solid guarantees for the efficient operation and stable performance of products.
